Technical Specs:
Delay Time -------------------------> 30 ms – 900 ms
Input impedance --------------------> 470 kΩ
Output impedance -------------------> 1 kΩ
Power supply -----------------------> 9VDC, 2.1mm tip negative, 55mA
Switch -----------------------------> True bypass
Dimensions -------------------------> 119x94x56mm (4.7x3.7x2.2")
